$460
|
- Compact size allows for convenient mounting or stowage
- Floats upright without an external float collar
- Test mode with LED indicator allows readiness check
- Highly flexible, fixed antenna always in position, ready for use
- Transmits simultaneously on 121.5 MHz (civilian) and 243.0 MHz
(military) Search and Rescue homing frequencies
- Lanyard is coiled on spindle for easy, non-tangling deployment and
stowage
- High impact plastic case designed to withstand exposure to sea water
and raft packing
- 5-year limited warranty
- Designed for quick, easy battery replacement at any ACR Authorized
Service Center
- Extra long life lithium battery; 6-year replacement life (12-year
useful life)
- Operating life is 48 hours, @ -20°C (-4°F) longer in temperate
waters
| Size: |
9.0 x 4.8 x 3.5 in (22.9 x 12.2 x 8.9 cm), Antenna
7.3 in (18.4 cm) |
| Weight: |
1.7 lbs (790 g) |
| Material: |
Polycarbonate |
| Color: |
High-viz optic yellow |
| Deployment: |
Manual/floats upright |
| Operation: |
Hold switch left, pull yellow key out, release
switch; blinking light indicates unit is transmitting. |
| Accessories: |
9318 - Mounting bracket |
| Certification: |
U.S. FCC; Germany; CE |
| Limited Warranty: |
5 years |
| Waterproof: |
32.8 ft (10 m) |
| Carton Dimensions: |
6.0 x 9.0 x 13.0 in (13.0 x 23.0 x 33.0 cm) |
| Units Per Carton: |
2 |
| Carton Weight: |
6.0 lbs (2.7 kg) |
| Frequency: |
121.5 MHz, 243.0 MHz |
| Battery Type: |
Lithium |
| Modulation: |
AM |
| Radiated Power: |
75 mW minimum |
| Operational Life: |
48 hours @ -20°C (-4°F), longer in temperate
waters |
|
|
|
|
|
